URL Monitoring
URL monitoring focuses on providing information about the integrated main domain, offering a monitoring function that concentrates on this aspect.
In addition to the URL data provided in the transactions, it also provides URL data by configured segments to optimize monitoring traffic conditions.
Screen Configuration
-
Segment URL Data: Displays call and response data collected from URLs registered in the current segment.
- Data is aggregated and displayed on a daily basis.
- Average call count: The average number of calls per minute collected during the day
- Maximum call count: The maximum number of calls per minute collected during the day
- Average response time: The average total response time collected during the day
- Maximum response time: The maximum response time collected during the day
-
URL Data: Displays call and response data collected from all URLs corresponding to the main domain.
- Data is aggregated and displayed on a daily basis.
- Detailed items are the same as Segment URL Data.
- Compare URL data and Segment URL Data to check if segment deployment for traffic control is appropriate.
-
URL Status Indicators: Displays a list of URLs where calls occur.
- Displays the top ten URLs in order of slowest response time.
- Data is updated and reflected on a minute-by-minute basis.
- Changing the date and time will output data for that time period.
- URLs set for traffic control are marked next to the URL in the color of the respective segment. For Section Control, only the set start/end URLs are displayed.
-
Per-Minute Accumulated Call Count
- Displays per-minute accumulated data of call counts collected from all URLs included in the main domain.
- Data up to 5 minutes before the designated time is displayed, with the default being the current time. If a specific date and time are set, the data for 5 minutes at that time will be displayed.
-
Per-Minute Average Response Time
- Displays trends in the response time of calls collected from all URLs included in the main domain on a per-minute basis.
- Data up to 5 minutes before the designated time is displayed, with the default being the current time. If a specific date and time are set, the data for 5 minutes at that time will be displayed.
